MS46SF1-1Y05AIR
Bluetooth 5.0 low energy module
MS46SF11 is compact size, highly flexible, ultra-low power wireless BLE 5.0 Module based on nRF52805 SoCs. With a powerful 32-bit ARM Cortex® M4 CPU, a 192KB flash memory, a 24KB RAM and integrating a 2.4 GHz Transceiver, the module can offer perfect solution for Bluetooth connectivity.
MS46SF11 is ideal for cost-constrained applications. It is the best choice for applications such as beacons, disposable medical devices, sensors etc.
Product Characteristics
- Highly Integrated Solution
- With Nordic nRF52805 ARM Cortex-M4 processor
- Integrated external 32.768K crystal oscillator
- PCB Trace Antenna support external antenna connection, Metal Shied
- 192KB Flash and 24KB RAM
- Support Preload Minew High Speed Slave Uart Firmware
- Support iBeacon Broadcast Mode
Specification
| Product Variants: | MS46SF1-1Y05AIR |
| PCB Antenna: | √ |
| Chip Inside: | nRF52805 |
| Bluetooth Qualification: | v5.0(Bluetooth Low Energy) |
| Bluetooth low Energy Output Power EIRP[dBm]: | 4 |
| Maximum Range [m]: | 100 |
| Maximum Number Of Connections: | 8 |
| Standalone Module Open CPU: | √ |
| UART: | 2 |
| SPl: | 2 |
| TwI (2C compatible): | 1 |
| GPIO: | 6 |
| ADC: | 2 |
| PWM: | 1 |
| Minimum Supply [M]: | 1.7 |
| Maximum Supply [M]: | 3.6 |
| Maximum Temperature [C]: | 85 |
| Minimum Temperature [C]: | -40 |
| Size [mm]: | 20×12× 2 |
