G1 Gateway
It’s a faster and safer gateway with powerful BLE & Wi-Fi CPU and WPA 2.0 enterprise encryption for data security and transmission, G1 collects data from BLE Beacon, sensor and other IoT devices, and then sends it to the cloud over Wi-Fi / Ethernet. It’s a great option for all industry applications.
How it works
Applications
A Faster and Greater Connection
Minew's G1 Gateway can be widely used in different vertical industries, such as shopping malls, airports, supermarkets, places of entertainment, concert, hospitals, schools, museums, companies, enterprises, administrative units, government departments, factories, logistics, etc., making asset tracking, access control, advertisement promotion, indoor positioning, and industrial automation become possible.
General Information
| Color | White |
| Size | 150x150x36mm |
| Net Weight | 180g |
| Accessory | 1x USB cable, mental fixing and screws |
| Power supply (Vcc) | DC 5.0 (+/- 5%) Max. 5.5 Volts |
| Storage temperature | -40℃ to 85℃ |
| Humidity | Max 95%, non-condensing, relative humidity |
WiFi RF Performance
| Wireless | IEEE 802.11b/g/n (single stream) |
| Data rate | IEEE 802.11b, 1-11Mbps
IEEE 802.11g, 6-54Mbps IEEE 802.11n(2.4GHz), 7.2-72.2Mbps |
| Frequency band | 2.400 – 2.484 GHz |
| Number of selectable Subchannels | 14 channels |
| Maximum receive input level | -10dBm(with PER < 8%@11Mbps)
-20dBm(with PER < 10%@54Mbps) -20dBm(with PER < 10%@MCS7) |
| Minimum receive input level | -87dBm(typ. with PER < 8%@11Mbps)
-70dBm(typ. with PER < 10%@54Mbps) -70dBm(typ. with PER < 10%@MCS7) |
| Transmit Power | 17dBm(typical)@802.11b
11.3dBm(typical)@802.11g 8.2dBm(typical)@802.11n |
| Range | up to 90 meters( in open space) |
BLE RF Performance
| Item | Parameters |
| RF Power Accuracy | +/- 4 dB |
| Receiver Sensibility | -108dBm@250kbps, 0.1% BER
-93dBm@1Mbps, 0.1 %BER |
| Maximum Received Signal Strength at <0.1% PER | 0dBm |
| Frequency Deviation | +/-250 kHz @BLE |
| Scanning & concurrently process | 300 BLE packets per second |
| Range | up to 300 meters in open space |
